Features:
1. Easy to install, there are screw holes on housing.
2. 45 degree between lighting direction and installation surface, higher
lighting utilization.
3. Driver on board solution, no need external driver, different input voltages
optional.
4. IP65 design with full PC housing, very safe.
5. Use frosted PC cover, make light soft.
6. The longest length can be 2.1m.
Technical datas:
Size:
Suitable for Freezer, fish tank, display cabinet, furniture, plant breeding room, aisle, corridor, balcony, light box, etc
Technical datas:
|
Length |
Item |
Input Volt. |
LED |
IP Rating |
Effiency |
Watt. |
|
300mm |
BL-RBX3Q-300 |
220V/DC24V/DC12V |
SMD2835 |
IP65 |
100lm/W |
3W |
|
500mm |
BL-RBX3Q-500 |
220V/DC24V/DC12V |
SMD2835 |
IP65 |
100lm/W |
5W |
|
600mm |
BL-RBX3Q-600 |
220V/DC24V/DC12V |
SMD2835 |
IP65 |
100lm/W |
6W |
|
900mm |
BL-RBX3Q-900 |
220V/DC24V/DC12V |
SMD2835 |
IP65 |
100lm/W |
8W |
|
1000mm |
BL-RBX3Q-1000 |
220V/DC24V/DC12V |
SMD2835 |
IP65 |
100lm/W |
12W |
|
1200mm |
BL-RBX3Q-1200 |
220V/DC24V/DC12V |
SMD2835 |
IP65 |
100lm/W |
10W |
|
1400mm |
BL-RBX3Q-1400 |
220V/DC24V/DC12V |
SMD2835 |
IP65 |
100lm/W |
12W |
|
1500mm |
BL-RBX3Q-1500 |
220V/DC24V/DC12V |
SMD2835 |
IP65 |
100lm/W |
13W |
|
1700mm |
BL-RBX3Q-1700 |
220V/DC24V/DC12V |
SMD2835 |
IP65 |
100lm/W |
16W |
Size:
The length can be 0.2-3m, depand on customers‘ requirements.
The wattage can be adjusted according to customers‘ requirements.
The color can be made according to the customer‘s request.
Sample can be offered for testing
Suitable for Freezer, fish tank, display cabinet, furniture, plant breeding room, aisle, corridor, balcony, light box, etc
